7MBR35VM120-50

Product Overview

7MBR35VM120-50 is a Fuji Electric IGBT power module from the 6th Generation V Series, designed as a compact PIM module for inverter and power conversion applications. The module integrates a converter diode bridge, dynamic brake circuit and three-phase inverter bridge in one package. With a 1200V voltage class and 35A current rating, it is suitable for motor drive inverters, NC servo systems, UPS equipment and maintenance or replacement projects that require a compact Fuji PIM IGBT module.

Key Features

• Manufacturer: Fuji Electric

• Part Number: 7MBR35VM120-50

• Device Type: IGBT power module

• Product Category: Power semiconductor / PIM IGBT module

• Series: 6th Generation V Series

• Module Type: PIM / Power Integrated Module

• Circuit Configuration: PIM with converter diode bridge, dynamic brake circuit and three-phase inverter bridge

• Voltage Class: 1200V

• Collector-Emitter Voltage: 1200V

• Collector Current: 35A at 25°C class

• Gate-Emitter Voltage: ±20V maximum class

• Power Dissipation: 210W class

• Maximum Junction Temperature: 175°C class

• IGBT Section: Integrated three-phase IGBT inverter bridge

• Rectifier Section: Built-in converter diode bridge

• Brake Section: Built-in dynamic brake circuit

• Key Features: Low VCE(sat), compact package, PCB mounting structure, converter diode bridge and dynamic brake circuit

• Typical Use: Inverters, NC servos, UPS systems, motor drive equipment and compact power conversion circuits

• Ordering / Packaging Note: Buyers should verify the full Fuji Electric datasheet, suffix “-50”, terminal layout, package outline, mounting instructions, thermal design and inverter circuit requirements before production use.

Applications

7MBR35VM120-50 can be used in power electronics systems that require a compact PIM IGBT module with rectifier, brake and inverter functions integrated in one package. Typical applications include inverter motor drives, NC servo systems, uninterruptible power supplies, industrial automation equipment, small-capacity power conversion systems, CNC equipment, control cabinets, maintenance projects and repair applications. It is also suitable for BOM review where a Fuji Electric 1200V / 35A class PIM IGBT module is required.

Quality & Sourcing

Antrex Electronics can support 7MBR35VM120-50 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find part requests for sourcing assistance.
