2MBI600U2E-060

Product Overview

2MBI600U2E-060 is a Fuji Electric high-current IGBT power module from the U2 Series, designed for demanding industrial power conversion and motor control applications. This 600V, 600A dual IGBT module adopts a 2-Pack (2-in-1) configuration with integrated free-wheel diodes, delivering low conduction loss, high switching efficiency and excellent thermal performance. Packaged in the rugged M247 housing with an electrically isolated baseplate, it is well suited for industrial inverters, motor drives, welding equipment, UPS systems and high-power converters.

Key Features

• Manufacturer: Fuji Electric

• Part Number: 2MBI600U2E-060

• Product Type: IGBT Power Module

• Series: U2 Series

• Configuration: 2-Pack (2-in-1)

• Collector-Emitter Voltage (VCES): 600V

• Continuous Collector Current (IC): 600A

• Pulse Collector Current (IC Pulse): 1200A

• Gate-Emitter Voltage (VGES): ±20V

• Maximum Junction Temperature (Tvj max): 150°C

• Package Type: M247

• Integrated Free-Wheel Diodes: Yes

• Isolation Voltage: 2500VAC (1 minute)

• Mounting Type: Screw Mount

• Module Structure: Electrically Isolated Baseplate

• Cooling Method: Heatsink Mounting

• Features: Low switching loss, low saturation voltage, high current capability and high reliability

• Product Status: Maintenance Product

• Typical Applications: Industrial inverters, AC motor drives, welding machines, UPS systems, power converters and induction heating equipment

• Ordering Note: Buyers should verify electrical ratings, package dimensions, lifecycle status and the latest Fuji Electric datasheet before production use.

Applications

2MBI600U2E-060 is designed for high-current industrial switching applications requiring reliable performance and efficient power conversion. Typical applications include variable frequency drives (VFDs), industrial motor drives, servo systems, uninterruptible power supplies (UPS), welding equipment, industrial power converters, induction heating systems, renewable energy converters and other heavy-duty power electronic equipment.

Quality & Sourcing

Antrex Electronics can support 2MBI600U2E-060 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required delivery date, packaging requirements and application details for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label verification, visual inspection and third-party testing support when required. OEMs, industrial equipment manufacturers, repair centers and electronic component buyers are welcome to submit BOM lists or hard-to-find power semiconductor requirements for sourcing assistance.
