MC13851EPR2
IC RF AMP GPS 1GHZ-2.5GHZ 8MLPD
Quick Answer: MC13851EPR2 is a RF amplifier or RF front-end gain device from Freescale Semiconductor / NXP.
- Manufacturer
- Freescale Semiconductor
- Product Category
- RF Amplifiers
- Package
- 8-UFDFN Exposed Pad
- Stock
- 2,752 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Freescale Semiconductor |
|---|---|
| Product Category | RF Amplifiers |
| Current - Supply | 4.8mA |
| Frequency | 1GHz ~ 2.5GHz |
| Gain | 16.4dB |
| Min Qty | 523 |
| Mounting Type | Surface Mount |
| Noise Figure | 1.1dB |
| P1dB | 8dBm |
| Package | Bulk |
| Product status | Active |
| RF Type | General Purpose |
| Supplier Device Package | 8-MLPD (2x2) |
| Test Frequency | 2.14GHz |
| Voltage - Supply | 2.3V ~ 3V |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for MC13851EPR2.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for MC13851EPR2
Product Overview
MC13851EPR2 is a RF amplifier or RF front-end gain device from Freescale Semiconductor / NXP. In an RF design it is normally used as a gain, driver or receiver-front-end stage in an RF signal chain, so the useful sourcing checks are not only the ordering code but also the operating band, gain behavior, output level, package footprint and bias conditions.
For this model, the key application data to verify are: exact frequency range must be verified on the manufacturer part page for this base number; gain, noise figure, output compression and linearity are part-number specific; and RF IC or module bias per datasheet. Because RF amplifier parts are layout- and matching-sensitive, MC13851EPR2 should be treated as an exact-BOM item unless the replacement has been validated with the same matching network, thermal design and control conditions.
Key Features
- Manufacturer: Freescale Semiconductor / NXP
- Part Number: MC13851EPR2
- Device Type: RF amplifier or RF front-end gain device
- Signal-Chain Role: gain, driver or receiver-front-end stage in an RF signal chain
- Frequency / Band: exact frequency range must be verified on the manufacturer part page for this base number
- Gain / NF / Linearity: gain, noise figure, output compression and linearity are part-number specific
- Output Power / Compression: small-signal, driver or PA output class depends on the base family
- Supply / Bias: RF IC or module bias per datasheet
- RF Interface: 50 Ω RF path or RF IC pins depending on package
- Package / Mounting: surface-mount RF IC, MMIC, transistor or connectorized module depending on base number
- Design Note: verify S-parameters, matching network, thermal pad/flange and control pins before substituting this RF amplifier
Applications
- wireless equipment
- RF test systems
- communications modules
- exact-BOM replacement sourcing
