UPC8215TU-A
IC AMP GPS 1575.42MHZ 8MINIMOLD
Quick Answer: UPC8215TU-A is a NEC/CEL RF MMIC amplifier from CEL / Renesas.
- Manufacturer
- CEL
- Product Category
- RF Amplifiers
- Package
- 8-SMD, Flat Lead Exposed Pad
- Stock
- 809 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | CEL |
|---|---|
| Product Category | RF Amplifiers |
| Current - Supply | 10mA ~ 13mA |
| Frequency | 1575.42MHz |
| Gain | 24dB ~ 30dB |
| Min Qty | 0 |
| Mounting Type | Surface Mount |
| Noise Figure | 1.3dB ~ 1.5dB |
| P1dB | 5dBm |
| Package | Bulk |
| Product status | Obsolete |
| RF Type | GPS |
| Supplier Device Package | 8-MINIMOLD |
| Test Frequency | 1575.42MHz |
| Voltage - Supply | 2.7V ~ 3.3V |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for UPC8215TU-A.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for UPC8215TU-A
Product Overview
UPC8215TU-A is a NEC/CEL RF MMIC amplifier from CEL / Renesas. In an RF design it is normally used as a RF/IF gain block or CATV/receiver gain stage, so the useful sourcing checks are not only the ordering code but also the operating band, gain behavior, output level, package footprint and bias conditions.
For this model, the key application data to verify are: uPC RF amplifier families cover VHF/UHF through microwave IF bands; exact bandwidth depends on base number; gain, noise figure, output power and IP3 per uPC/CEL datasheet; and low-voltage RF MMIC bias. Because RF amplifier parts are layout- and matching-sensitive, UPC8215TU-A should be treated as an exact-BOM item unless the replacement has been validated with the same matching network, thermal design and control conditions.
Key Features
- Manufacturer: CEL / Renesas
- Part Number: UPC8215TU-A
- Device Type: NEC/CEL RF MMIC amplifier
- Signal-Chain Role: RF/IF gain block or CATV/receiver gain stage
- Frequency / Band: uPC RF amplifier families cover VHF/UHF through microwave IF bands; exact bandwidth depends on base number
- Gain / NF / Linearity: gain, noise figure, output power and IP3 per uPC/CEL datasheet
- Output Power / Compression: small-signal gain-block output level
- Supply / Bias: low-voltage RF MMIC bias
- RF Interface: 50 Ω RF input/output in compact SMT package
- Package / Mounting: surface-mount RF IC, MMIC, transistor or connectorized module depending on base number
- Design Note: verify S-parameters, matching network, thermal pad/flange and control pins before substituting this RF amplifier
Applications
- receiver gain stages
- CATV and broadband equipment
- wireless modules
- legacy Japanese RF board replacement
