MAX19794ETX+
RF ATTENUATOR 0-46.4DB 36WFQFN
Quick Answer: The MAX19794ETX+ from Analog Devices / Maxim Integrated is a Dual analog voltage-variable attenuator designed for controlled signal reduction in 50-ohm RF paths.
- Manufacturer
- Maxim Integrated
- Product Category
- RF Attenuators
- Package
- 36-WFQFN Exposed Pad
- Stock
- 2 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Maxim Integrated |
|---|---|
| Product Category | RF Attenuators |
| Attenuation Value | 0dB ~ 46.4dB |
| Frequency Range | 500 MHz ~ 4 GHz |
| Impedance | 50 Ohms |
| Min Qty | 1 |
| Package | Tube |
| Product status | Active |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for MAX19794ETX+.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for MAX19794ETX+
Product Overview
The MAX19794ETX+ from Analog Devices / Maxim Integrated is a Dual analog voltage-variable attenuator designed for controlled signal reduction in 50-ohm RF paths. It provides 44.7 dB cascaded; 22.4 dB per attenuator across a documented 10 MHz to 500 MHz operating range. The device is documented for applications including Automatic level control, Wireless infrastructure, Receiver and transmitter gain control.
Key Features
- Attenuator Type: Dual analog voltage-variable attenuator
- Frequency Range: 10 MHz to 500 MHz
- Attenuation Range: 44.7 dB cascaded; 22.4 dB per attenuator
- Input IP3: >+34.4 dBm
- Supply Voltage: Single +5 V or +3.3 V supply
- Control Interface: Analog voltage or on-chip SPI-controlled 10-bit DAC
- Impedance: 50 ohms
- Package: 36-pin 6 mm × 6 mm TQFN with exposed pad
- Operating Temperature: -40°C to +100°C
Applications
- Automatic level control
- Wireless infrastructure
- Receiver and transmitter gain control
- VSAT and test equipment
