HMC453QS16GETR
IC AMP CDMA 400MHZ-2.2GHZ 16QSOP
Quick Answer: HMC453QS16GETR is a Hittite / Analog Devices microwave MMIC amplifier from Analog Devices.
- Manufacturer
- Analog Devices Inc.
- Product Category
- RF Amplifiers
- Package
- 16-SSOP (0.154", 3.90mm Width) Exposed Pad
- Stock
- 582 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Analog Devices Inc. |
|---|---|
| Product Category | RF Amplifiers |
| Current - Supply | 725mA |
| Frequency | 400MHz ~ 2.2GHz |
| Gain | 20.5dB |
| Min Qty | 500 |
| Mounting Type | Surface Mount |
| Noise Figure | 9dB |
| P1dB | 32.5dBm |
| Package | Tape & Reel (TR) |
| Product status | Active |
| RF Type | CDMA, GSM, WCDMA |
| Supplier Device Package | 16-QSOP-EP |
| Test Frequency | 400MHz |
| Voltage - Supply | 5V |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for HMC453QS16GETR.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for HMC453QS16GETR
Product Overview
HMC453QS16GETR is a Hittite / Analog Devices microwave MMIC amplifier from Analog Devices. In an RF design it is normally used as a microwave gain, driver or power-amplifier stage, so the useful sourcing checks are not only the ordering code but also the operating band, gain behavior, output level, package footprint and bias conditions.
For this model, the key application data to verify are: GHz-band microwave coverage is exact-base specific; many HMC/ADPA parts are narrowband or broadband MMICs; gain, Psat/P1dB, OIP3 and NF must be matched to the exact HMC/ADPA base; and positive/negative gate or drain bias as specified by the MMIC family. Because RF amplifier parts are layout- and matching-sensitive, HMC453QS16GETR should be treated as an exact-BOM item unless the replacement has been validated with the same matching network, thermal design and control conditions.
Key Features
- Manufacturer: Analog Devices
- Part Number: HMC453QS16GETR
- Device Type: Hittite / Analog Devices microwave MMIC amplifier
- Signal-Chain Role: microwave gain, driver or power-amplifier stage
- Frequency / Band: GHz-band microwave coverage is exact-base specific; many HMC/ADPA parts are narrowband or broadband MMICs
- Gain / NF / Linearity: gain, Psat/P1dB, OIP3 and NF must be matched to the exact HMC/ADPA base
- Output Power / Compression: MMIC output power and thermal limit per ADI datasheet
- Supply / Bias: positive/negative gate or drain bias as specified by the MMIC family
- RF Interface: 50 Ω RF/microwave ports, sometimes die or ceramic SMT package
- Package / Mounting: surface-mount RF IC, MMIC, transistor or connectorized module depending on base number
- Design Note: verify S-parameters, matching network, thermal pad/flange and control pins before substituting this RF amplifier
Applications
- microwave radios
- radar and aerospace RF modules
- test instrumentation
- point-to-point links
Quality & Sourcing
Antrex Electronics can support sourcing for HMC453QS16GETR and related RF amplifier BOM lines, including exact part-number matching, lot-label review, packaging inspection and third-party testing support when the project requires additional verification.
