ADUM3224WBRZ-RL7
DGTL ISO 3KV 2CH GATE DVR 16SOIC
- Manufacturer
- Analog Devices Inc.
- Product Category
- Optocouplers / Photocouplers
- Package
- 16-SOIC (0.154", 3.90mm Width)
- Stock
- 1,004 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Analog Devices Inc. |
|---|---|
| Product Category | Optocouplers / Photocouplers |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Current - Peak Output | 4A |
| Grade | Automotive |
| Min Qty | 1000 |
| Mounting Type | Surface Mount |
| Number of Channels | 2 |
| Operating Temperature | -40°C ~ 125°C |
| Package | Tape & Reel (TR) |
| Product status | Active |
| Propagation Delay tpLH / tpHL (Max) | 54ns, 54ns |
| Rise / Fall Time (Typ) | 12ns, 12ns |
| Supplier Device Package | 16-SOIC |
| Technology | Magnetic Coupling |
| Voltage - Isolation | 3000Vrms |
| Voltage - Output Supply | 4.5V ~ 18V |
| Datasheet | View Datasheet PDF |
