AD603SQ/883BQ

Product Overview

AD603SQ_883BQ is commonly associated with Analog Devices AD603SQ/883B, a low-noise voltage-controlled variable gain amplifier designed for RF, IF and automatic gain control applications. The device provides accurate linear-in-dB gain control with pin-selectable gain ranges, supporting -11dB to +31dB operation at 90MHz bandwidth or +9dB to +51dB operation at 9MHz bandwidth. With low input-referred noise, military-grade screening option and 8-CERDIP package, it is suitable for radar receivers, communication systems, instrumentation, AGC loops and high-reliability analog signal processing designs.

Key Features

• Manufacturer: Analog Devices

• Part Number: AD603SQ_883BQ / AD603SQ/883B

• Equivalent Military Reference: 5962-9457203MPA commonly referenced in ADI documentation

• Device Type: Variable gain amplifier

• Product Category: Linear IC / special-purpose amplifier

• Amplifier Channels: 1 circuit

• Gain Control Type: Voltage-controlled, linear-in-dB gain control

• Gain Range Option 1: -11dB to +31dB with 90MHz bandwidth

• Gain Range Option 2: +9dB to +51dB with 9MHz bandwidth

• Bandwidth: 90MHz maximum gain-range configuration

• Input-Referred Noise: 1.3nV/√Hz typical

• Recommended Supply Voltage: ±5V supplies commonly used

• Power Consumption: 125mW typical at recommended ±5V supplies

• Input Resistance: 100Ω attenuator input resistance

• Package: 8-CERDIP / ceramic DIP package

• Pin Count: 8 pins

• Mounting Type: Through-hole

• Grade / Screening: /883B military-grade screening option

• Operating Temperature Range: Military temperature range should be verified from the AD603SQ/883B military datasheet

• Typical Use: RF AGC, IF AGC, radar receiver gain control and precision signal-level adjustment

• Key Features: Low noise, 90MHz bandwidth, calibrated linear-in-dB gain control and high-reliability ceramic package

• Datasheet PDF: https://www.analog.com/media/en/technical-documentation/data-sheets/ad603.pdf

• Product Page: https://www.analog.com/en/products/ad603.html

• Ordering / Packaging Note: Buyers should verify the full Analog Devices ordering code, /883B screening status, package marking, date code, lead finish, storage condition and military documentation requirements before production or repair use.

Applications

AD603SQ_883BQ / AD603SQ/883B can be used in analog and RF systems that require accurate voltage-controlled gain adjustment with low noise and wide bandwidth. Typical applications include RF automatic gain control circuits, IF gain control stages, radar receiver front ends, communication receivers, ultrasound signal chains, test and measurement equipment, data acquisition front ends, high-reliability instrumentation, military electronics and legacy board repair projects. It is also suitable for BOM review where an Analog Devices low-noise 90MHz variable gain amplifier in 8-CERDIP package is required.

Quality & Sourcing

Antrex Electronics can support AD603SQ_883BQ / AD603SQ/883B sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required screening level, date code, package marking, lead finish requirement and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection, pin inspection and third-party testing support when required. OEMs, EMS providers, aerospace suppliers, communication equipment manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find amplifier IC requests for sourcing assistance.
