Logic ICs

About Logic ICs

Logic ICs perform fixed digital functions used to control, route, store or translate binary signals. The category includes gates, inverters, buffers, transceivers, multiplexers, decoders, counters, flip-flops, latches, registers, comparators, parity devices and multivibrators. These parts provide deterministic control, signal conditioning, bus expansion and voltage-domain interfacing in embedded, industrial, automotive, computing and communication equipment.

Select the required logic function, channel count and truth table first, then choose a compatible logic family. Check supply range, input thresholds, output levels and drive current, including whether inputs are TTL-compatible, Schmitt-triggered or overvoltage tolerant. Compare propagation delay, maximum switching rate, quiescent and dynamic current, fan-out, output type and power-off behavior. For sequential devices, verify clock edge, setup and hold times, reset state and enable controls. Confirm package, pinout, temperature grade and automotive or other qualification before substitution.
