C5354
C5354 is an NPN high-voltage power transistor for fast switching regulator applications
- 제품 카테고리
- 바이폴라 트랜지스터 - BJT
- 패키지
- TO-3P
- 재고
- 1,500 개
- 공급 가능 여부
- 현재 수량은 확인이 필요합니다.
제품 특성
| 제조사 | Toshiba Semiconductor and Storage |
|---|---|
| 제품 카테고리 | 바이폴라 트랜지스터 - BJT |
| Application | High-speed switching |
| Base-Emitter Saturation Voltage | 1.5V Max |
| Collector Current | 5A |
| Collector Power Dissipation | 100W |
| Collector-Base Voltage | 900V |
| Collector-Emitter Saturation Voltage | 1V Max |
| Collector-emitter voltage | 800V |
| DC Current Gain | 8 to 15 |
| Emitter-Base Voltage | 7V |
| Fall Time | 0.5µs Typ |
| Material | Silicon |
| Mounting Type | Through Hole |
| Operating Junction Temperature | 150°C max |
| Package Type | TO-3P(N) |
| Polarity | NPN |
| Recommended Use | Switching Regulators / DC-DC Converters |
| Rise Time | 0.7µs Typ |
| Storage Temperature Range | -55°C to +150°C |
| Storage Time | 3.0µs Typ |
| Technology | Triple Diffused Type |
| 데이터시트 | 데이터시트 PDF 보기 |
조달 개요
C5354의 주요 공급 및 구매 정보입니다.
왜 Antrex Electronics인가요?
검증된 소싱, 검사 및 글로벌 조달 요구에 대해 독립 유통 지원을 제공합니다.
독립 유통 지원
생산 및 조달 요구에 맞춰 수급난, 단종 및 구하기 어려운 전자부품 소싱을 지원합니다.
추적성 검토
주문 확정 전에 라벨, Lot, Date Code 및 제공 가능한 공급망 문서를 검토할 수 있습니다.
검사 및 테스트
필요 시 외관 검사, X-ray 및 제3자 테스트 지원을 진행할 수 있습니다.
글로벌 조달 지원
OEM, EMS 및 유통업체의 국제 조달 요구를 지원하며 단일 부품부터 BOM 프로젝트까지 대응합니다.
인증 및 검증 지원
전자부품 조달을 위한 품질 관리, 추적성 검토 및 검사 지원을 제공합니다.
C5354 상세 설명
Product Overview
C5354 is a Toshiba 2SC5354 silicon NPN triple diffused power transistor designed for high-speed and high-voltage switching applications. The device features an 800V collector-emitter voltage rating, 5A collector current capability and fast switching characteristics. With TO-3P(N) package construction, it is suitable for switching regulators, high-voltage DC-DC converters, power supplies and industrial power switching circuits.
Key Features
Manufacturer: Toshiba Electronic Devices & Storage Corporation
Part Number: C5354 / 2SC5354
Device Type: Silicon NPN Triple Diffused Power Transistor
Product Category: Bipolar Junction Transistor (BJT)
Polarity: NPN
Collector-Base Voltage (VCBO): 900V
Collector-Emitter Voltage (VCEO): 800V
Emitter-Base Voltage (VEBO): 7V
Collector Current (IC): 5A
Pulse Collector Current (ICP): 8A
Base Current (IB): 2A
Collector Power Dissipation: 100W
DC Current Gain (hFE): 15 to 60 (Depending on Test Conditions)
Collector-Emitter Saturation Voltage: 1.0V Maximum
Switching Time: Fast Switching Performance (tr 0.7μs, tf 0.5μs Typical Maximum)
Technology: Triple Diffused Structure
Package Type: TO-3P(N)
Pin Count: 3 Pins
Mounting Type: Through Hole
Operating Junction Temperature: +150°C Maximum
Application Type: Switching Regulators, DC-DC Converters and High-Voltage Power Switching
Compliance: RoHS Compatible
Ordering / Packaging Note: Buyers should verify manufacturer marking, package type, pin configuration and electrical parameters before production use.
Applications
C5354 / 2SC5354 is designed for high-voltage switching circuits requiring fast switching response and reliable power handling. Typical applications include switching regulators, high-voltage power supplies, DC-DC converter circuits, industrial control equipment, inverter circuits, electronic repair projects and replacement applications for discontinued power transistors.
Quality & Sourcing
Antrex Electronics can support C5354 / 2SC5354 sourcing with stock availability checks, RFQ quotation, manufacturer verification, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, required manufacturer, target price, packaging requirements and application information for faster quotation support.
For quality control, Antrex Electronics can help arrange product photos, marking review, visual inspection, pin verification and third-party testing support when required. OEMs, EMS providers, industrial equipment manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find transistor requests for sourcing assistance.
Datasheet
