V23086-R1802-A803
TE Connectivity V23086-R1802-A803 is a compact automotive micro relay with 30A switching capability and sensitive coil design
- 제조사
- TE Connectivity
- 제품 카테고리
- 자동차용 릴레이
- 패키지
- DIP
- 재고
- 1,500 개
- 공급 가능 여부
- 현재 수량은 확인이 필요합니다.
제품 특성
| 제조사 | TE Connectivity |
|---|---|
| 제품 카테고리 | 자동차용 릴레이 |
| Applications | Automotive Electronics, Wiper Control, Door Lock Systems, Seat Control, Lighting Systems |
| Coil Resistance | Approx. 181 Ω |
| Coil Type | Sensitive Coil |
| Coil Voltage | 12 VDC |
| Compliance | ROHS compliant |
| Contact Arrangement | 1 Form C (CO / SPDT) |
| Contact Current Rating | 30 A Continuous Current |
| Contact Material | AgSnO₂ with Wiper Load Capability |
| Contact Switching Capacity | High Current Automotive Load Switching |
| Mounting Type | PCB Through Hole / THR Mount |
| Operate Voltage | Low Power Sensitive Coil Design |
| Operating Temperature Range | -40°C to +125°C |
| Package Type | Sealed Micro Relay Housing |
| Product Type | Automotive PCB Relay |
| Protection Feature | Vented PCB THR Version |
| Relay Configuration | Single Relay |
| Relay Series | Micro Relay K (THT - THR) |
| Release Voltage | Low Release Voltage Design |
| Switching Voltage | Up to 14 VDC Automotive Applications |
| Terminal Style | PCB Terminal |
| Weight | Low Weight Compact Design |
| 데이터시트 | 데이터시트 PDF 보기 |
조달 개요
V23086-R1802-A803의 주요 공급 및 구매 정보입니다.
왜 Antrex Electronics인가요?
검증된 소싱, 검사 및 글로벌 조달 요구에 대해 독립 유통 지원을 제공합니다.
독립 유통 지원
생산 및 조달 요구에 맞춰 수급난, 단종 및 구하기 어려운 전자부품 소싱을 지원합니다.
추적성 검토
주문 확정 전에 라벨, Lot, Date Code 및 제공 가능한 공급망 문서를 검토할 수 있습니다.
검사 및 테스트
필요 시 외관 검사, X-ray 및 제3자 테스트 지원을 진행할 수 있습니다.
글로벌 조달 지원
OEM, EMS 및 유통업체의 국제 조달 요구를 지원하며 단일 부품부터 BOM 프로젝트까지 대응합니다.
인증 및 검증 지원
전자부품 조달을 위한 품질 관리, 추적성 검토 및 검사 지원을 제공합니다.
V23086-R1802-A803 상세 설명
Product Overview
V23086-R1802-A803 is a TE Connectivity (Tyco Electronics) Micro Relay K series automotive PCB relay designed for compact power switching applications. This single relay features a sensitive 12V DC coil, 1 Form C (SPDT) contact configuration and AgSnO₂ contact material optimized for demanding automotive loads. With a continuous current capability up to 30A, low power consumption and reliable THR (Through-Hole Reflow) mounting design, V23086-R1802-A803 is suitable for automotive electronics, body control modules, power distribution systems and industrial control applications.
Key Features
Manufacturer: TE Connectivity (Tyco Electronics)
Part Number: V23086-R1802-A803
Product Type: Automotive Micro Relay
Series: V23086 Micro Relay K Series
Relay Type: PCB Single Relay
Contact Arrangement: 1 Form C (SPDT / 1 CO)
Coil Voltage: 12V DC
Coil Type: Sensitive Coil
Contact Material: AgSnO₂ (Silver Tin Oxide) wiper load type
Continuous Current Rating: 30A maximum
Switching Configuration: Changeover contact
Mounting Type: Through-Hole Reflow (THR)
Terminal Style: PCB terminal
Enclosure Type: Vented housing design
Coil Resistance: Approx. 181Ω
Coil Power: Sensitive coil low power operation
Switching Voltage: Automotive DC switching applications
Mechanical Life: High durability for automotive applications
Operating Temperature Range: -40°C to +125°C
Application Standard: Automotive relay applications
Features: Compact size, low noise operation, high current capability and reliable switching performance
Typical Applications: Automotive control modules, power distribution units, door control systems, lighting systems, seat control and industrial equipment
Product Status: Legacy automotive relay, available through specialized sourcing channels
Datasheet: V23086-R1802-A803 datasheet PDF available for technical verification before production use.
Applications
V23086-R1802-A803 is designed for reliable switching of medium-power electrical loads in automotive and industrial systems. Typical applications include automotive body electronics, window lifters, door locks, lighting control, HVAC systems, power management modules, industrial controllers and other PCB-based relay switching systems.
Quality & Sourcing
Antrex Electronics can support V23086-R1802-A803 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, customers can provide quantity requirements, delivery schedules, application details and technical specifications for faster quotation support.
For quality assurance, Antrex Electronics can assist with product photos, marking verification, visual inspection and third-party testing services when required. OEM manufacturers, automotive electronics suppliers, industrial equipment companies and electronic component buyers are welcome to submit BOM lists or hard-to-find relay requirements for sourcing assistance.
