NCT3012S TR

Product Overview

The NCT3012S TR from Nuvoton Technology Corporation is a specialized power management integrated circuit intended for desktop and notebook PC power-saving control. The device operates from a 5 V supply and draws 2 mA of supply current. It is offered in a surface-mount 8-SOIC package with 0.154 in, 3.90 mm width, and an 8-ESOP package designation. The specified operating temperature range is 0°C to 70°C. The part is a PMIC for power-saving control in personal computer platforms, with the supply, thermal, and package parameters above defining its technical context.

Key Features

• Power-saving control function for desktop and notebook PC applications
• 5 V supply voltage
• 2 mA supply current
• Operating temperature range of 0°C to 70°C
• Surface-mount package
• 8-SOIC package with 0.154 in, 3.90 mm width
• 8-ESOP package designation
• Specialized PMIC classification

Applications

• Power-saving control in desktop PC systems
• Power-saving control in notebook PC systems

Design & Procurement Notes

When selecting the NCT3012S TR, confirm that the host board provides a 5 V supply to the device and that the 2 mA supply current is included in the power budget. Verify that the expected operating temperature remains within 0°C to 70°C. The surface-mount 8-SOIC package with 0.154 in, 3.90 mm width and 8-ESOP package designation should be checked against the required pad geometry and assembly process. Because the device is described for desktop and notebook PC power-saving control, review the surrounding power management circuitry to ensure the implementation matches the intended PC platform use.
