MAX2769CETI+

Product Overview

MAX2769CETI+ from Analog Devices / Maxim Integrated is a universal GNSS receiver. This RF receiver entry is prepared for engineering and sourcing teams that need a practical summary of the receiver architecture, operating band and interface considerations.

The description below focuses on receiver function, RF band, modulation support, power/interface notes and supply-chain usage for BOM sourcing.

Key Features

• Manufacturer: Analog Devices / Maxim Integrated
• Part Number: MAX2769CETI+
• Device Type: universal GNSS receiver
• Receiver Architecture: Single-conversion GNSS receiver
• GNSS Coverage: L1/E1, B1 and G1 bands for GPS, Galileo, BeiDou and GLONASS
• Application Class: Industrial and wide consumer GNSS receiver applications
• Baseband Interface: Supports analog I/Q outputs and on-chip ADC-based digital interface options
• Integration: Complete GNSS RF receiver chain on one chip
• Process: Low-power SiGe BiCMOS receiver technology
• Package / Case: Manufacturer package code from ordering suffix; check mechanical drawing before PCB release
• Design Notes: Set LNA path, IF bandwidth and ADC/baseband format to match the GNSS baseband processor.

Applications

GNSS navigation modules, industrial positioning, asset tracking, mobile devices and embedded location receivers.

Single-chip GNSS front ends where multi-constellation L1/E1/B1/G1 coverage and flexible baseband interface are required.

Quality & Sourcing

Antrex Electronics can support sourcing for MAX2769CETI+ through available stock checks, BOM consolidation and alternative-lot checking. For RF receiver ICs, lot/date code, package condition, moisture sensitivity handling and original labeling should be checked before shipment.

For project builds or shortage support, Antrex Electronics can coordinate visual inspection, packaging verification and third-party electrical or authenticity testing when required. This helps buyers manage risk when sourcing discontinued, legacy or hard-to-find RF receiver parts.
